NBX-DE-4AES-3G

3G/HD/SD-SDI Audio De-Embedder 4 AES/EBU Outputs

The NBX-DE-4AES-3G from MultiDyne provides a cost-effective miniature solution to demux four AES/EBU digital audio signals from a 3G/HD/SD-SDI signal.

The NBX-DE-4AES-3G accepts one SIDE signal and provides one reclocked SDI output on BNC connectors. The four DIP switch assignable AES/EBU outputs are also provided on BNC connectors.

A dual-color LED indicator provides an SDI signal status indication. A green LED indicates the unit is locked to a valid SDI signal while a red LED indicates a valid SDI signal is not present at the input.

When illuminated green the four LED’s labeled G1, G2, G3, G4 indicate that AES/EBU audio is detected in those groups and is available to be de-embedded. If the LED is not illuminated this indicates that audio is not resent in the respective group.

Power to the NBX-DE-4AES-3G is provided by an external AC Adapter with a locking DC connector supplied with the module.

Features

  • Excellent Value
  • Compact Size
  • Rugged Steel Enclosure
  • Highest of Quality Components

Applications

  • Live Broadcast
  • Arenas and Stadiums
  • Shared Control Rooms
  • Campus Facilities
